Plastic Sprockets
Plastic Sprockets
| Tooth | P.D. | O.D. | Part # | Weight |
|---|---|---|---|---|
| 16T | 1.282" | 1.407” | RHS-250-16 | .059 oz |
| 18T | 1.440" | 1.568” | RHS-250-18 | .083 oz |
| 20T | 1.598" | 1.729" | RHS-250-22 | .110 oz |
| 22T | 1.757" | 1.889" | RHS-250-22 | .141 oz |
| 24T | 1.955" | 2.049" | RHS-250-24 | .175 oz |
| 26T | 2.074" | 2.209" | RHS-250-26 | .213 oz |
| 28 | 2.233" | 2.372" | RHS-250-28 | .255 oz |
| 30T | 2.392" | 2.529" | RHS-250-30 | .3 oz |
| 32T | 2.551" | 2.688" | RHS-250-32 | .349 oz |
| 34T | 2.712" | 2.853" | RHS-250-34 | .401 oz |
| 36T | 2.870" | 3.014" | RHS-250-36 | .457 oz |
| 38T | 3.029" | 3.175" | RHS-250-38 | .517 oz |
| 40T | 3.188" | 3.336" | RHS-250-40 | .580 oz |
| 42T | 3.346" | 3.497" | RHS-250-42 | .647 oz |
| 44T | 3.505" | 3.658" | RHS-250-44 | .717 oz |
| 46T | 3.664" | 3.818" | RHS-250-46 | .791 oz |
| 48T | 3.823" | 3.979" | RHS-250-48 | .869 oz |
| 50T | 3.981" | 4.140" | RHS-250-50 | .950 oz |
| 52T | 4.140" | 4.301" | RHS-250-52 | 1.04 oz |
| 54T | 4.299" | 4.462" | RHS-250-54 | 1.13 oz |
| 56T | 4.458" | 4.623" | RHS-250-56 | 1.22 oz |
| 58T | 4.616" | 4.784" | RHS-250-58 | 1.32 oz |
| 60T | 4.775" | 4.945" | RHS-250-60 | 1.41 oz |
| 62T | 4.934" | 5.106" | RHS-250-62 | 1.52 oz |
| 64T | 5.092" | 5.266" | RHS-250-64 | 1.62 oz |
| 66T | 5.521" | 5.427" | RHS-250-66 | 1.73 oz |
| 68T | 5.410" | 5.588" | RHS-250-68 | 1.85 oz |
| 70T | 5.569" | 5.749" | RHS-250-70 | 1.96 oz |
| 72T | 5.727" | 5.910" | RHS-250-72 | 2.08 oz |
| 74T | 5.886" | 6.071" | RHS-250-74 | 2.21 oz |
| 76T | 6.045" | 6.232" | RHS-250-76 | 2.34 oz |
| 78T | 6.204" | 6.393" | RHS-250-78 | 2.47 oz |
| 80T | 6.362" | 6.554" | RHS-250-80 | 2.60 oz |
| 82T | 6.521" | 6.714" | RHS-250-82 | 2.74 oz |
| 84T | 6.680" | 6.875" | RHS-250-84 | 2.88 oz |
| 86T | 6.838" | 7.036" | RHS-250-86 | 3.03 oz |
| 88T | 6.997" | 7.197" | RHS-250-88 | 3.18 oz |
| 90T | 7.156" | 7.358" | RHS-250-90 | 3.33 oz |
| 92T | 7.315" | 7.519" | RHS-250-92 | 3.49 oz |
| 94T | 7.473" | 7.680" | RHS-250-94 | 3.65 oz |
| 96T | 7.632" | 7.841" | RHS-250-96 | 3.82 oz |
| 98T | 7.791" | 8.002" | RHS-250-98 | 3.98 oz |
| 100T | 7.950" | 8.162" | RHS-250-100 | 4.15 oz |
Now it is easier than ever to design your project with metal or plastic chain. Our plastic hub sprockets are not only extremely strong but lightweight as well. The sprockets are 0.100” thick, accept standard 0.25” (1/4”) metal or plastic chain, and work well with our 0.770” aluminum hubs.
Product Quick Detail:
- Standard and non-standard available
- With high quality and competitive price
- Prompt delivery
- Packing as per customer’s demand.
We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.
Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.
Materials Available
1. Stainless Steel: SS201, SS303, SS304, SS316, SS416, SS420
2. Steel:C45(K1045), C46(K1046),C20
3. Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58), C27200(CuZn37), C28000(CuZn40)
4. Bronze: C51000, C52100, C54400, etc
5. Iron: 1213, 12L14,1215
6. Aluminum: Al6061, Al6063
7.OEM according to your request
Surface Treatment
Annealing, natural canonization, heat treatment, polishing, nickel plating, chrome plating, zinc plating,yellow passivization, gold passivization, satin, Black surface painted etc.
Processing Method
CNC machining, punch,turning, milling, drilling, grinding, broaching, welding and assembly
QC & Certificate
Technicians self-check in production,final-check before package by professional Quality inspector
ISO9001:2008 , ISO14001:2001,ISO/TS 16949:2009
Package & Lead Time
Size: Drawings
Wooden Case/Container and pallet, or as per customized specifications.
15-25days samples. 30-45days offcial order
Port: Shanghai/Ningbo port
