Worm Gearbox

Worm Gear Reducers

A worm gearbox is a type of reduction gear that is used to convert high motor speed input into lower speed output while also maintaining high torque. The worm producer consists of a gear in the form of a screw meshed into the machine which outputs in the right angle orientation. The worm gearbox is mostly made of bronze with steel or stainless steel worm. The size of the worm reducer is very small and sleek compared to other gear reducers which makes it very handy for rated motor speed and space problems.

Uses of Worm Gearbox?

The worm gearboxes are applied in fields like tuning instruments, elevators, escalators, conveyor belts, medical equipment, power transmission systems, and security gates to name a few.

Types of worm gearbox?

There are 44 series of worm gearboxes classified according to transmission application.

Request a free quote

What is the worm gearbox used for?
A worm gear (or worm drive) is a specific gear composition in which a screw (worm) meshes with a gear/wheel similar to a spur gear. The set-up allows the user to determine rotational speed and also allows for higher torque to be transmitted.

How does a worm gear work?
How Worm Gears Work. An electric motor or engine applies rotational power via to the worm. The worm rotates against the wheel, and the screw face pushes on the teeth of the wheel. The wheel is pushed against the load.

Can a worm gear go both directions?
Worm drives can go either direction, but they need to be designed for it. As you can imagine, turning the worm shaft under load will create a thrust along the axis of the screw. However, if you reverse the direction the direction of thrust will reverse as well.

How do you find the gear ratio of a worm gear?
Number of Threads in Worms
The number of threads in a worm is the number of teeth in a worm. The speed transmission ratio of a worm and worm gear set is obtained by dividing the number of teeth of the worm gear by the number of threads of the worm.

These are further available in different ratios. The RV reducers are available in the ratios of 5:1 to 100:1. The worm gearboxes are also classified according to their uses and structure, some of them are – Shaft to bore, flange mount, NEMA flange, miniature, high- ratio reduction, compact, and molded glass-filled housing. You can also get it modified according to specific or particular needs.

Benefits of worm gearbox?

The basic benefit of the worm gearbox is that it produces an output of ninety degrees to the input with higher torque and lower speed. In addition to the benefits of high-speed reduction and torque multiplication, the worm gearbox also provides for shock absorption, quiet operation, smaller size, and the adjustable mounting position. This makes the worm reducer the best quality reducer for heavy applications.

Worm Gear Reducer Service factor & Installation notice
