High Precision Planetary Gearbox Replacement of APEX AB180

Category: High Precision Planetary Gearbox

Description

High Precision Planetary Gearbox Replacement of APEX AB180

High Precision Planetary Gearbox Replacement of APEX AB180, also known as servo motor planetary gearbox and low backlash planetary gearbox, is a type of gearbox designed to transmit power between the servo motor and the load with high precision and low backlash. It is widely used in various industrial applications where high-precision motion control is required, such as machine tools, robotics, and automation equipment.

Our High Precision Planetary Gearbox can perfectly replace APEX brand gearboxes. The installation method, external dimensions, and technical parameters are all similar to those of APEX brand. We do not sell APEX brand products, and we only mention the APEX brand model for the convenience of customers.

Parameters	Values
Output torque (1-stage)	3 Nm - 200 Nm
Output torque (2-stage)	8 Nm - 600 Nm
Ratios	3 - 100
Emergency stop torque	2.5 times of rated torque
Nominal input speed	3000 - 6000 rpm
Max input speed	10000 rpm
Micro backlash	< 3 arcmin
Reduced backlash	< 5 arcmin
Standard backlash	< 8 arcmin
Torsional rigidity	> 14 Nm/arcmin
Max radial load	5000 N
Max axial load	2500 N
Service life	20000 hours
Efficiency	> 95%
Weight	0.5 kg - 20 kg
Operating temp	-10°C - 90°C
Lubrication	Lubricated for life
Degree of gearbox protection	IP65
Mounting position	Any orientation
Noise	< 65 dB(A)

We can also customize different sizes of gearboxes to meet customers' specific requirements.

Advantages of Our High Precision Planetary Gearbox

High precision and low backlash
Compact design and light weight
High torsional rigidity and load capacity
Long service life and high efficiency
Easy to integrate with various servo motors

Our High Precision Planetary Gearbox can significantly improve the performance and reliability of the whole motion control system compared to other brands of gearboxes.

Application Areas of High Precision Planetary Gearbox

Our High Precision Planetary Gearbox is widely used in various industrial applications, such as:

Machine tools - for precise positioning and high-speed machining
Robotics - for accurate motion control and repeatability
Automation equipment - for smooth and reliable operation
Medical devices - for precise and stable motion control
Printing machinery - for high-precision printing and registration
Packaging machinery - for smooth and consistent packaging

Our High Precision Planetary Gearbox can help improve the performance and efficiency of these applications, and ensure the accuracy and repeatability of the motion control system.

About Our Company

We are EVER-POWER, a professional manufacturer of transmission equipment located in Hangzhou, Zhejiang. We specialize in research, production, and sales of various types of gearboxes, couplings, and other power transmission products.

Our products are manufactured in strict accordance with international quality management system standards ISO9001:2015, and have passed China Compulsory Certification (CCC) and European Union CE Certification. We use international standard materials and manufacturing processes to produce products that meet or exceed the advanced level of similar products worldwide.

Our Advantages

Advanced production equipment and testing instruments
Professional technical team with years of experience in the industry
Strict quality control system and complete after-sales service
Customized solutions and flexible production capabilities
Competitive price and fast delivery time

Our aim is to provide high-quality products and services to our customers, and to become a reliable partner in their success.

Author: Miya

Product Quick Detail:

Standard and non-standard available
With high quality and competitive price
Prompt delivery
Packing as per customer’s demand.

We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.

Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.

pruduct quality report

Materials Available

1. Stainless Steel: SS201, SS303, SS304, SS316, SS416, SS420
2. Steel:C45(K1045), C46(K1046),C20
3. Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58), C27200(CuZn37), C28000(CuZn40)
4. Bronze: C51000, C52100, C54400, etc
5. Iron: 1213, 12L14,1215
6. Aluminum: Al6061, Al6063
7.OEM according to your request
product materials available

Surface Treatment

Annealing, natural canonization, heat treatment, polishing, nickel plating, chrome plating, zinc plating,yellow passivization, gold passivization, satin, Black surface painted etc.

Processing Method

CNC machining, punch,turning, milling, drilling, grinding, broaching, welding and assembly
product finishing

QC & Certificate

Technicians self-check in production,final-check before package by professional Quality inspector
ISO9001:2008 , ISO14001:2001,ISO/TS 16949:2009

Package & Lead Time

Size: Drawings
Wooden Case/Container and pallet, or as per customized specifications.
15-25days samples. 30-45days offcial order
Port: Shanghai/Ningbo port
product packages
