Metric Gear Rack

Metric Gear Rack

Category: Tag:

Precsion Grade: (JIS Grade 5) 7e25                                                    Hardening: Tooth area carburized(HRC42-48)
Material:(S45C Medium Carbon Steel)C45                                           Side Ground: Included
Type: Helical Rack                                                                             Pressure Angle: 20°
Treatment of Teeth: Milled                                                                 Right helix angle: 19°31′42″
Module L L2 Tooth No. B A0 A1 D I Hole No. A C1 C2 E D1 I1 C3 Pitch Error  /300mm
1 1000 3.14 300 15 15 14 - - - - - - - - - - 0.02
1.5 1000 6.7 200 19 19 17.5 62.5 125 8 8 7 11 7 31.7 936.6 5.7 0.03
2 1000 8.5 150 24 24 22 62.5 125 8 8 7 11 7 31.7 936.6 5.7 0.031
2.5 1000 8.5 120 24 24 21.5 62.5 125 8 9 7 11 7 31.7 936.6 5.7 0.033
3 1000 10.3 100 29 29 26 62.5 125 8 9 10 15 9 35 930 7.7 0.035
4 1000 13.8 75 39 39 35 62.5 125 8 12 10 15 9 33.3 933 7.7 0.038
5 1000 17.4 60 49 39 34 62.5 125 8 12 14 20 13 37.5 925 11.7 0.04
6 1000 20.9 50 59 49 43 62.5 125 8 16 18 26 17 37.5 925 15.7 0.042
8 1000 28.7 36 79 79 71 60 120 8 25 22 33 21 120 720 19.7 0.045
10 1000 35.11 30 99 99 89 62.5 125 8 32 33 48 32 125 750 19.7 0.052

Rack and pinion is utilized to convert rotational motion to linear motion. A rack is straight teeth cut into one surface of rectangular or cylindrical rod shaped material, and a pinion is a small cylindrical gear meshing with the rack. There are many ways to categorize gears. If the relative position of the gear shaft is used, a rack and pinion belongs to the parallel shaft type.

Quick Detail:

  • Standard and non-standard available
  • With high quality and competitive price
  • Prompt delivery
  • Packing as per customer’s demand.

We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.

Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.

    pruduct quality report
