Synchronous Pulley

Description

14M Standard belt width 115mm
Spcfctn	Z	Shape	Dp	De	W	L	1K	X	Dm	d	E	F	M	F
28-14M	28	A/B	124.78	121.98	128	153	120	-	92	25	-	137	106	F-25137106
29-14M	29	A/B	129.23	126.44	128	153	120	-	94	25	-	141	111	F-25141111
30-14M	30	A/B	133.69	130.90	128	153	120	-	96	25	-	146	115	F-25146115
32-14M	32	A/B	142.60	139.81	128	153	120	-	100	25	-	155	123	F-25155123
34-14M	34	A/B	151.52	148.72	128	153	120	-	104	25	-	164	132	F-25164132
36-14M	36	A/B	160.43	157.63	128	153	120	-	108	30	-	173	140	F-25173140
38-14M	38	A/B	169.34	166.55	128	153	120	-	112	30	-	182	149	F-25182149
40-14M	40	B/W	178.25	175.46	128	153	120	26	114	30	136	190	158	F-25190158
42-14M	42	B/W	187.17	184.37	128	153	120	26	116	30	145	200	167	F-25200167
44-14M	44	B/W	196.08	193.28	128	153	120	26	118	30	154	208	176	F-25208176
46-14M	46	B/W	204.99	202.20	128	153	120	26	118	30	163	217	185	F-25217185
48-14M	48	B/W	213.90	211.11	128	153	120	26	120	30	172	226	194	F-25116194
56-14M	56	B/W	249.55	246.76	128	153	120	26	124	40	207	262	229	F-25262229
60-14M	60	B/W	267.38	364.59	128	153	120	26	128	40	225	280	247	F-25280247
64-14M	64	B/W	285.21	282.41	128	153	120	26	130	40	243	297	265	F-25297265
72-14M	72	B/W	320.86	318.06	128	153	120	26	134	50	279	333	301	F-25333301
80-14M	80	B/W	356.51	353.71	128	153	120	26	138	50	314	369	336	F-25369336
84-14M	84	B/W	374.33	371.54	128	153	120	26	140	50	332	387	354	F-25387354
90-14M	90	B/W	401.07	398.28	128	153	120	26	142	50	359	413	381	F-25413381
96-14M	96	B/W	427.81	425.01	128	153	120	26	146	50	385	440	407	F-25440407
112-14M	112	B/W	499.11	496.32	128	153	120	26	154	50	457	-	-	-
144-14M	144	B/W	641.71	638.92	128	153	120	26	170	60	600	-	-	-

Each of the two sides with wheels were mounted bearings
Adopting high quality Aluminum Alloy material，sturdy and durable
Adopt surface oxidation treatment, anti-Rust and Anti-corrosion effectively
Widely used in milling machine, gear shaper, drilling machine, CNC engine lathe, hobbing machine or other machinery transmission occasions

Product Quick Detail:

Standard and non-standard available
With high quality and competitive price
Prompt delivery
Packing as per customer’s demand.

We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.

Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.

pruduct quality report

Materials Available

1. Stainless Steel: SS201, SS303, SS304, SS316, SS416, SS420
2. Steel:C45(K1045), C46(K1046),C20
3. Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58), C27200(CuZn37), C28000(CuZn40)
4. Bronze: C51000, C52100, C54400, etc
5. Iron: 1213, 12L14,1215
6. Aluminum: Al6061, Al6063
7.OEM according to your request
product materials available

Surface Treatment

Annealing, natural canonization, heat treatment, polishing, nickel plating, chrome plating, zinc plating,yellow passivization, gold passivization, satin, Black surface painted etc.

Processing Method

CNC machining, punch,turning, milling, drilling, grinding, broaching, welding and assembly
product finishing

QC & Certificate

Technicians self-check in production,final-check before package by professional Quality inspector
ISO9001:2008 , ISO14001:2001,ISO/TS 16949:2009

Package & Lead Time

Size: Drawings
Wooden Case/Container and pallet, or as per customized specifications.
15-25days samples. 30-45days offcial order
Port: Shanghai/Ningbo port
