Square Bore Sprockets

Square Bore Sprockets

Category: Tag:

# OF TEETH
SPROCKET
OUTSIDE DIAMETER
550 CHAIN
6 5506 3.98
7 5507 4.48
8 5508 4.98
9 5509 5.49
10 55010 6.00
11 55011 6.51
12 55012 7.02
13 55013 7.53
14 55014 8.05
15 55015 8.56
16 55016 9.08
17 55017 9.59
18 55018 10.11
19 55019 10.62
20 55020 11.14
555 CHAIN
6 5556 3.94
7 5557 4.43
8 5558 4.94
9 5559 5.44
10 55510 5.95
11 55511 6.46
12 55512 6.97
13 55513 7.49
14 55514 8.00
15 55515 8.52
16 55516 9.03
17 55517 9.55
18 55518 10.06
19 55519 10.58
20 55520 11.10
557 CHAIN
6 5576 3.98
7 5577 4.48
8 5578 4.98
9 5579 5.49
10 55710 6.00
11 55711 6.51
12 55712 7.02
13 55713 7.53
14 55714 8.05
15 55715 8.56
16 55716 9.08
17 55717 9.59
18 55718 10.11
19 55719 10.62
20 55720 11.14
620 CHAIN
6 6206 4.02
7 6207 4.53
8 6208 5.04
9 6209 5.55
10 62010 6.07
11 62011 6.59
12 62012 7.11
13 62013 7.63
14 62014 8.15
15 62015 8.67
16 62016 9.19
17 62017 9.72
18 62018 10.24
19 62019 10.76
20 62020 11.29

Finished-Bore Sprockets are provided with standard keyway and 2 set screws. The keyway is for fixing your sprocket to the shaft to keep the sprocket from spinning. One set screw is located over the key and one is located 90 degrees to the key for locking onto the shaft.

Quick Detail:

  • Standard and non-standard available
  • With high quality and competitive price
  • Prompt delivery
  • Packing as per customer’s demand.

We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.

Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.

    pruduct quality report

    Materials Available

    1. Stainless Steel: SS201, SS303, SS304, SS316, SS416, SS420
    2. Steel:C45(K1045), C46(K1046),C20
    3. Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58), C27200(CuZn37), C28000(CuZn40)
    4. Bronze: C51000, C52100, C54400, etc
    5. Iron: 1213, 12L14,1215
    6. Aluminum: Al6061, Al6063
    7.OEM according to your request
    product materials available

    Surface Treatment

    Annealing, natural canonization, heat treatment, polishing, nickel plating, chrome plating, zinc plating,yellow passivization, gold passivization, satin, Black surface painted etc.

    Processing Method

    CNC machining, punch,turning, milling, drilling, grinding, broaching, welding and assembly
    product finishing

    QC & Certificate

    Technicians self-check in production,final-check before package by professional Quality inspector
    ISO9001:2008 , ISO14001:2001,ISO/TS 16949:2009

    Package & Lead Time

    Size: Drawings
    Wooden Case/Container and pallet, or as per customized specifications.
    15-25days samples. 30-45days offcial order
    Port: Shanghai/Ningbo port
    product packages

    FAQ

    Q: Are you trading company or manufacturer ?
    A: Our group consists in 3 factories and 2 abroad sales corporations.

    Q: Do you provide samples ? is it free or extra ?
    A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

    Q: How long is your delivery time ? What is your terms of payment ?
    A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shipment.

    Q: What is the exact MOQ or price for your product ?
    A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation.
