HINGE TOP SPROCKETS

HINGE TOP SPROCKETS

Category: Tag:

Steel Hinge Top Conveyor Chain Sprockets with or without shroud plates in a range of tooth sizes.

1 5/8″ Through Bore – No Hub Projection – Mandrel Bore – For S-815 And Other Flat Top Conveyor Chain Of Same Specifications

Sprockets with 19, 21, 23 and 25 teeth stocked with and without center groove. Add suffix ‘G’ to part number.

Effective number of teeth is one half of listed number so chain contacts alternate teeth each revolution. For this reason, odd numbers of teeth are listed and recommended, although other sizes can be supplied if required. For smooth operation, sprockets of 19teeth or more are recommended.

Standard sprockets are made from C1040 steel and are completely machined to provide the finest quality available. Sprockets of stainless steel, bronze or other materials can be made to order.

Product Quick Detail:

  • Standard and non-standard available
  • With high quality and competitive price
  • Prompt delivery
  • Packing as per customer’s demand.

We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.

Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.

pruduct quality report

Materials Available

1. Stainless Steel: SS201, SS303, SS304, SS316, SS416, SS420
2. Steel:C45(K1045), C46(K1046),C20
3. Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58), C27200(CuZn37), C28000(CuZn40)
4. Bronze: C51000, C52100, C54400, etc
5. Iron: 1213, 12L14,1215
6. Aluminum: Al6061, Al6063
7.OEM according to your request
product materials available

Surface Treatment

Annealing, natural canonization, heat treatment, polishing, nickel plating, chrome plating, zinc plating,yellow passivization, gold passivization, satin, Black surface painted etc.

Processing Method

CNC machining, punch,turning, milling, drilling, grinding, broaching, welding and assembly
product finishing

QC & Certificate

Technicians self-check in production,final-check before package by professional Quality inspector
ISO9001:2008 , ISO14001:2001,ISO/TS 16949:2009

Package & Lead Time

Size: Drawings
Wooden Case/Container and pallet, or as per customized specifications.
15-25days samples. 30-45days offcial order
Port: Shanghai/Ningbo port
product packages
