Qurd reduktoru-Fenner C seriyasının dəyişdirilməsi spiral qurd sürət qutusu mil quraşdırılmış reduktor-fırlanma anı qolu ilə ikiqat/üçqat azaldıcı 875

Giriş

The Worm Reducer-Replacement of Fenner Series C Helical Worm Gearbox Shaft Mounted Reducer-with Torque Arm Double/Triple Reduction 875 is a high-powered gear mechanism designed for efficient and energy-saving direct drive. It offers various installation options and can easily be interchanged with leading market competitors in terms of size and compatibility with standard IEC motors. The modern design technology and high-quality components make the C Series helical worm gear reducer superior to any other gearbox in terms of cost-effectiveness per Nm. Our company specializes in providing replacement parts for Fenner brand helical worm gearboxes, offering high-quality products with competitive prices. It is important to note that our products are replacement parts and not original factory parts. For original factory parts, please contact the original supplier for purchase.

Xüsusiyyətləri

• Transmissiya nisbəti 8:1-dən 16.000:1-ə qədər, maksimum 10.000 Nm fırlanma anı ilə
• Available in 8 different specifications
• Bore range from 20mm to 90mm
• Highly efficient and energy-saving right-angle drive mechanism
• Efficient gear transmission for energy and operational cost savings
• Interchangeable with products from other manufacturers in terms of size
• Innovative motor adapter using standard IEC interface
• Oil-sealed gearbox prevents oil leakage during motor disassembly
• Multiple installation options: base, flange, or shaft mounting

Qurd Reduktorun strukturu

Qurd Reduktoru aşağıdakı komponentlərdən ibarətdir:

1. Worm shaft: Transfers rotation and torque
2. Worm gear: Meshes with the worm shaft, converting rotation into a right-angle drive
3. Housing: Encloses and protects the worm shaft and worm gear
4. Bearing: Supports the rotating components and reduces friction
5. Seals: Prevents lubricant leakage and protects against external contaminants
6. Gearbox flange: Enables mounting of the reducer to other equipment
7. Input and output shafts: Connects the reducer to the driving and driven components
8. Torque arm: Provides additional stability and support for the reducer

Tətbiqlər

The Worm Reducer is suitable for various applications, including:

• Machinery industry: Used in various machinery such as conveyors, mixers, and crushers
• Food industry: Provides reliable power transmission for food processing equipment
• Car washing industry: Ensures smooth and efficient operation of car wash systems
• Packaging industry: Enables precise and reliable packaging processes
• Transmission industry: Used in power transmission systems for smooth operation
• Automation industry: Provides dependable drive systems for automated machines
• Solar energy industry: Supports solar tracking mechanisms for optimal energy capture

Quraşdırma

The performance of the Worm Reducer depends on proper installation, lubrication, and maintenance. Here are the installation instructions for different mounting methods:

Shaft Mounting

1. Ensure the shaft and gear unit holes for mounting are clean and free from burrs.
2. Apply a sufficient amount of lubricating oil on the shaft and hole to aid assembly and prevent friction corrosion.
3. Slide the unit onto the driving shaft and fit the key.

Foot Mounting

1. Securely mount the unit on a sturdy structure.
2. Install an output extension shaft if required.
3. Use flexible couplings for connecting shafts and ensure the shaft misalignment is within the coupling's tolerance.
4. When installing pulleys or sprockets on two shafts, position them as close to the gearbox as possible.
5. Avoid striking the shafts during the installation or removal of transmission components to prevent bearing damage.

Yağlama və Baxım

Proper lubrication and maintenance are essential for the longevity and performance of the Worm Reducer. Follow these guidelines:

Yağlama

• Oil change: Gearboxes of size 870 and 871 are lubricated for life, except when operating in explosive environments. All other sizes require oil change based on the operating temperature of the equipment. Replace half of the oil in new gearboxes after 1000 hours of operation, one year, or the specified service life.

Baxım

Maintenance of the Worm Reducer includes:

• Regularly inspecting the reducer for any signs of wear or damage.
• Checking and tightening any loose fasteners.
• Inspecting and replacing worn-out seals or gaskets.
• Ensuring proper alignment of the driving and driven components.
• Following the manufacturer's guidelines for lubrication and oil change.

Fenner spiral qurd sürət qutusunun dəyişdirilməsi

Our company specializes in providing high-quality replacement helical worm gearboxes, offering the following advantages:

• Superior quality and competitive prices
• Direct replacement for Fenner brand gearboxes
• Wide range of specifications and compatibility

Please note that our products are replacement parts and not original factory parts. For original factory parts, please contact the original supplier for purchase. We also welcome custom orders based on customer drawings or samples.

Qurd dişli reduktorları üçün elektrik mühərrikləri

The Worm Reducer and electric motors have a symbiotic relationship, as they work together to provide efficient power transmission. Our company also offers a variety of electric motors for sale, ensuring seamless integration with our worm gear reducers.

Ever-power haqqında

We are a comprehensive transmission equipment manufacturer with over 15 years of experience in the design, production, and sales of speed reducers. Serving customers in Europe, America, Africa, Asia, and other regions, we have gained a reputation for providing high-quality products, excellent service, and competitive prices. Our advanced production and testing equipment, along with a team of industry professionals, enable us to deliver the highest standards of product quality and energy efficiency. Our gearboxes find wide application in various industries, including equipment manufacturing, food processing, packaging, and automation. We encourage customers to explore our products and contact us for purchases.
